USER MANUAL FOR WAVETREND TAGS
2.1.2 W-Series
Repetition rate = 0.4 seconds
Class (Wavetrend
info)
Tag transmitting Expected life
(Years)
Expected life (Years)
with tamper armed
1 PUK 2.8 2.4
2 PUK + AGE 2.6 2.2
3 PUK + WIEGAND 2.2 1.9
4 PUK + USER DATA
X X
5 PUK + WIEGAND +
AGE
1.8 1.66
6 PUK + USER DATA +
AGE
X X
7 PUK + WIEGAND +
USER DATA
X X
8 PUK + WIEGAND +
USER DATA + AGE
X X
Repetition rate = 1 seconds
Class (Wavetrend
info)
Tag transmitting Expected life
(Years)
Expected life (Years)
with tamper armed
1 PUK 6.2 4.5
2 PUK + AGE 5.6 4.2
3 PUK + WIEGAND 4.88 3.7
4 PUK + USER DATA
X X
5 PUK + WIEGAND +
AGE
4.1 3.2
6 PUK + USER DATA +
AGE
X X
7 PUK + WIEGAND +
USER DATA
X X
8 PUK + WIEGAND +
USER DATA + AGE
X X
