USER MANUAL FOR WAVETREND TAGS

2.2 MOVEMENT SENSING

Tags can be rotated through 360° degrees to achieve various sensitivity levels of movement sensing. Note

that the tag is rotated in the vertical plane (i.e. a wall mount).

Document No. Product No. Wavetrend Technologies Date Page

Sensitivity L&W-TG100-MS L&W-TG501-MS L&W-TG800-MS

Most Sensitive

Least Sensitive

Once the movement sensor has been activated, the Movement Alarm Counter will be incremented and the

tag will transmit four consecutive transmissions with a 0.4-second interval. Thereafter the tag movement

sensor will be de-activated for 1 second. The tag will then return to its normal state again. (i.e. sensor acti-

vated)
