USER MANUAL FOR WAVETREND TAGS
Repetition rate = 2 seconds
Class (Wavetrend
info)
Tag transmitting Expected life
(Years)
Expected life (Years)
with tamper armed
1 PUK 10 6.2
2 PUK + AGE 9.3 5.9
3 PUK + WIEGAND 8.2 5.4
4 PUK + USER DATA
X X
5 PUK + WIEGAND +
AGE
7.1 5
6 PUK + USER DATA +
AGE
X X
7 PUK + WIEGAND +
USER DATA
X X
8 PUK + WIEGAND +
USER DATA + AGE
X X
Repetition rate = 5 seconds
Class (Wavetrend
info)
Tag transmitting Expected life
(Years)
Expected life (Years)
with tamper armed
1 PUK 10 8
2 PUK + AGE 10 7.8
3 PUK + WIEGAND 10 7.5
4 PUK + USER DATA
X X
5 PUK + WIEGAND +
AGE
10 7.1
6 PUK + USER DATA +
AGE
X X
7 PUK + WIEGAND +
USER DATA
X X
8 PUK + WIEGAND +
USER DATA + AGE
X X
X – Contact Wavetrend for details.
