Manual

Straight Models
MODEL SIZE (DN) CONNECTION TYPE DIMENSION WEIGHT
A B
in mm in mm in mm lbs kgs
05
3
⁄8 10 NPT 1
1
⁄4 32 5
1
⁄4 133 0.34 0.15
05
1
⁄2 15 NPT 1
1
⁄4 32 5
1
⁄2 140 0.36 0.16
05-CPVC
1
⁄2 15 CPVC 1
1
⁄8 29 4
11
⁄16 118 0.10 0.05
05-H
3
⁄4 20 Hose 2 50 6
3
⁄8 162 0.48 0.20
05H-M1
3
⁄4 20 Hose 3
3
⁄16 81 6
11
⁄16 170 0.60 0.27
05-S
1
⁄2 15 Sweat 1 25 5
1
⁄2 140 0.30 0.14
05-S
3
⁄4 20 Sweat 1 25 4
7
⁄8 124 0.08 0.04
05-C
5
⁄8 16 OD Comp. 1
1
⁄4 32 5
5
⁄8 143 0.40 0.18
Tee Models
MODEL SIZE (DN) CONNECTION TYPE DIMENSION WEIGHT
A B
in mm in mm in mm lbs kgs
05-C-T
1
⁄4 8 OD Comp. 2
3
⁄4 70 4
13
⁄16 122 0.17 0.07
05-C-T
3
⁄8 10 OD Comp. 3 77 4
13
⁄16 122 0.17 0.07
05-CXT
3
⁄8 10 OD Comp. x Reverse Comp. Nut 2
13
⁄16 72 4
13
⁄16 122 0.17 0.07
05-CXT
5
⁄8 16 OD Comp. x Reverse Comp. Nut 3
1
⁄16 78 4
13
⁄16 122 0.18 0.08
05-PEX-T
3
⁄8 10 PEX 2
1
⁄4 58 4
11
⁄16 119 0.12 0.05
05-PEX-T
1
⁄2 15 PEX 2
1
⁄4 58 4
11
⁄16 119 0.12 0.05
Quick-Connect
MODEL SIZE (DN) CONNECTION TYPE DIMENSION WEIGHT
A B
in mm in mm in mm lbs kgs
05-QC
1
⁄2 15 Quick-Connect 3
5
⁄8 93 7
3
⁄8 187 .4 .18
05-QC
3
⁄4 20 Quick-Connect 3
3
⁄32 104 9
3
⁄4 247 .57 .26
Dimensions - Weight
Fig. 1
Standards
Meets requirements of ASSE Standard 1010 and listed
by IAPMO.
Installations
Watts Series 05 water hammer arrestors should always be
installed as close to the source of shock as possible - one
unit on each hot and cold water line.
Although they function in any orientation, Figure 1, 2 and
3 show the proper installation where the shock would be
absorbed most effectively.
B
A
B
B
A
A
1010
Watts 05
Watts 05
Watts 05
shock source
shock source
shock source
ES-05 1012 © 2010 Watts
USA: 815 Chestnut St., No. Andover, MA 01845-6098; www.watts.com
Canada: 5435 North Service Rd., Burlington, ONT. L7L 5H7; www.wattscanada.ca
A Watts Water Technologies Company
Fig. 3
Fig. 2
