User's Manual

User Guide 45
CHAPTER 4 Changing Your
Network Settings
A primary task to set up your WatchGuard® Firebox® X Edge is to con-
figure the network IP addresses. At a minimum, you must configure
the external network and the trusted network to let traffic flow
through the Edge. You can also set up the optional interface. Many
customers use the optional network for public servers. An example of a
public server is a Web server.
You can use the Quick Setup Wizard to set up your network IP
addresses. You can also manually set up or change your network IP
addresses on the Network page.
Using the Network Setup Wizard
The easiest procedure to set up your network IP addresses is with the
Network Setup Wizard.
1 To connect to the System Status page, type the IP address of the
trusted network in the browser.
The default IP address is: https://192.168.111.1.
2 From the navigation bar, select Wizards.
3 Next to Setup the primary network interfaces of the Firebox X
Edge, click Go.
