Operating instructions
Item # Model Dimensions Volts Watts Ohms Amps
TW-F10BS-HW Hardwired
23 5/8” (600mm)W
32” (811mm)H
4 ¾” (121mm)D
120 150 95 1.25
TW-F10BS-PL Plug-In
23 5/8” (600mm)W
32” (811mm)H
4 ¾” (121mm)D
120 150 95 1.25
The Innity Towel Warmers are constructed from Type 304 stainless steel
and have a brushed nish. The stainless steel tubing is pre-assembled
and tack welded together for rigidity. The Towel Warmer is heated by
a cULus listed wire. The tubing used to hang the Towel Warmer is also
made of Type 304 stainless steel polished to a brushed nish. The Plug-in
model is equipped with a UL-Listed plug with grounding pin that is 6 feet
(1.8m) long.
Innity Plug-In models is fed electricity into the Towel Warmer through
a cULus listed cord with grounded plug. The unit must be plugged into
an outlet that is properly grounded. The Innity Hardwired model is fed
electricity into the Towel Warmer via a section of stainless steel tubing. The
tubing can rotate to facilitate wiring. The tubing has an outside diameter
suitable to secure the rubber O-ring on the electrical cover plate. The
stainless steel tubing projects through the O-ring and into the front of the
2”x4” (51mm x 102mm) electrical junction box that is properly grounded.
This box is secured in the wall and a water resistant seal is made with the
use of the rubber O-ring. Power can then be fed to the control unit which
may be located anywhere in the room.
Innity Towel Warmers are cULus listed and are suitable for use in US
and Canadian markets. The timer is UL listed and CSA certied. The
Timer is humidity sealed to IEC standards for zone 1 (areas where it may
be splashed by water) and zone 2 (areas which are occasionally subject
to high humidity) and therefore suitable for installation in damp locations
such as bathrooms. The main electrical line feeding the Towel Warmer
must incorporate an Appliance Leakage Current Interrupter (ALCI) for
North America.
