CONTROL SPRAY™ XTRA DUTY OWNER‘S MANUAL READ THIS MANUAL FOR COMPLETE INSTRUCTIONS FRANÇAIS - P. 13 ESPAÑOL - P. 25 EN F ES wagner-group.com Watch a video manual at www.wagnerspraytech.com/controlsprayxtraduty 0720 • Form No.
IMPORTANT SAFETY INFORMATION TABLE OF CONTENTS GROUNDING INSTRUCTIONS IMPORTANT SAFETY INFORMATION.............................................. 2-3 CONTROLS AND FUNCTIONS............................................................ 4-5 SETUP......................................................................................................... 6-7 SPRAYER CONTROLS................................................................................ 8 SPRAYING....................................................
IMPORTANT SAFETY INFORMATION SAFETY HAZARDS • • HAZARD: EXPLOSION OR FIRE Flammable vapors, such as solvent and paint vapors, in work area can ignite or explode. PREVENTION: • For use with only water-based or mineral spirit-type materials with a minimum flash point of 100ºF (38ºC) — Do not spray or clean with liquids having a flash point of less than 100ºF (38ºC). Flash point is the temperature at which a fluid can produce enough vapor to ignite.
CONTROLS AND FUNCTIONS Cover release Turbine Filter housing Spray width lever ON/OFF switch ON/OFF switch Filter Air cap Lock N Go tab Material flow control Trigger Material container (1.
CONTROLS AND FUNCTIONS ON / OFF SWITCH The ON/ OFF switch turns the turbine ON (I) and OFF (0). No spray material will be delivered until trigger is pulled. MATERIAL FLOW CONTROL The material flow control knob determines the amount of material that is sprayed from the nozzle assembly. TRIGGER Pulling the trigger will deliver material from the material container to the nozzle assembly, where it is sprayed. NARROW SPRAY WIDTH LEVER The spray width lever determines the width of the spray pattern.
SETUP i For a video showing how to set up the Control Spray Xtra Duty, visit: www.wagnerspraytech.com/controlsprayxtraduty MATERIAL PREPARATION i Material to be sprayed may need to be strained to remove any impurities in the paint which may enter and clog the system. Impurities in the paint will give poor performance and a poor finish.
SETUP ASSEMBLY 1 2 NEVER point the spray gun at any part of the body. Make sure the power cord is unplugged. 1. Stir the spraying material thoroughly. 2. Fill the container. Use a strainer to remove any particles. 3 (see Thinning the Material, previous page, if thinning is required). 3. Align the pickup tube A If spraying downward, the angled end of the pickup tube should be pointing toward the front of the nozzle.
SPRAYER CONTROLS i For a video showing Control Spray Xtra Duty spraying tips and best practices, visit: www.wagnerspraytech.com/controlsprayxtraduty MATERIAL FLOW CONTROL i The material flow control will be factory-set at its lowest setting out of the box. Adjust as needed. • Turn the knob out (counterclockwise) for less flow. Generally, low material flow is needed for spraying smaller surface areas, such as corners, lattice, or spindles. • Turn the knob in (clockwise) for increased flow.
SPRAYING i Frequently wipe the nozzle tip with a damp rag when spraying to remove dried material. HOW TO SPRAY PROPERLY Even coat throughout • Turn the ON/OFF switch to ON (I) to turn on the turbine. No material will spray until the trigger is activated. • • Position the spray gun perpendicular to the spray surface. • Always apply a thin coat of material on the first pass and allow to dry before applying a second, slightly heavier coat.
CLEANUP i For a video showing cleanup of the Control Spray Xtra Duty, visit: www.wagnerspraytech.com/controlsprayxtraduty CLEANUP NOTES i 1 When cleaning, use the appropriate cleaning solution (warm, soapy water for water-based coatings, and mineral spirits for oil-based coatings. Special cleanup instructions for use with flammable solvents (must have a flashpoint above 100ºF (38ºC): • • • • i 2 Always flush spray gun outside. Area must be free of flammable vapors.
MAINTENANCE CLEANING THE FILTER PRESS Attention Before every use, you should inspect the air filter in the turbine to see if it is excessively dirty. If it is dirty, follow these steps to replace it. Never operate your unit without the air filters. Dirt could be sucked in and interfere with the function of the unit. 1. Press the tabs at the rear of the turbine. Slide the rear housing off of the back of the turbine. 2. Remove the dirty filter from the turbine and replace with a new one.
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Problem A: Little or no material flow 1. 2. 3. 4. 5. 1. 2. 3. 4. 5. 6. Air filter clogged. 7. Spray material too thick. 8. Nozzle seal missing or worn. Clean. Clean. Increase material flow setting. Remove and replace as tightly as possible. Tighten container. Check the air vent hole on the pick up tube - clean if clogged. 6. Change 7. Thin*. 8. Replace nozzle. Problem B: Material leaking 1. 2. 3. 4. 1. 2. 3. 4.
PARTS LIST • LISTE DE PIÈCES • LISTA DE PIEZAS Replacement parts available by calling customer service 1 On peut obtenir des pièces de rechange en appelant le Service à la clientèle. 2 Los repuestos están disponibles llamanado al servicio a clientes. 1-800-328-8251 # Part No. Nº de piéce Pieza No. 3 English Description Français Description Español Descripción Qty. Qte. Cant.
PARTS LIST • LISTE DE PIÈCES • LISTA DE PIEZAS 1 2 3 4 5 6 7 # Part No. Nº de piéce Pieza No.
LIMITED WARRANTY • GARANTIE LIMITÉE • GARANTÍA LIMITADA HVLP PAINT SPRAY EQUIPMENT This product, manufactured by Wagner Spray Tech Corporation (Wagner), is warranted against defects in material and work-manship for one year following date of purchase if operated in accordance with Wagner’s printed recommendations and instructions. This warranty does not cover damage resulting from improper use, accidents, user’s negligence or normal wear.
CONTROL SPRAY™ XTRA DUTY wagner-group.
