User manual

Scope of delivery
For 2-door vehicles
B 2 Control units
D 1 Cable harness
E 2 Connecting rods
F 2 Fastening clips
G 8 Sheet metal screws
H 2 Rails with punched holes
I 4 Fastening nuts
J 2 Cable conducts
For 4-door vehicles
B 2 Control units
C 2 Servo units
D 1 Cable harness
E 4 Connecting rods
F 4 Fastening clips
G 16 Sheet metal screws
H
4
Rails with punched holes
I 8 Fastening nuts
J 4 Cable conducts
H
E
F
B/C
I
G
Safety and installation instructions
Caution! To check the voltage in
electric cables, use only a diode
test lamp or a voltmeter. Test
lamps which light up take too
much current and the vehicle
electronics may be damaged.
Diode testlamp
Testlamp
Caution! To avoid damage, always ensure
that there is enough clearance for the drill bit
to emerge. Every drill hole must be deburred
and treated with a rust proofing agent.
or
Voltmeter
