User manual

Contents
Information for using the installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Safety and installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Tools required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation of the control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Adjustment central locking rod to original rod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Drill template. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Information for using the installation instructions
10
Warning! Safety precaution: Failure to observe this warning may result in
injury to persons or damage to material.
Caution! Safety precaution: Failure to observe this warning will result in
damage to material and affect the proper
functioning of magic lock ML-22/44.
u This symbol indicates installation steps which have to be carried out.
To ensure problem-free fitting, read these installation and operating instructions carefully
before starting work.
When changing the owner the installation and operating instructions must be presented.
Please pay attention to all according producer dates while working.
For cars with side-airbags built in the seats, detection for occupied and childrenseats
please take note of the corresponding information of each manufacturer.
Product description Ref. No.
Universal contact for sliding doors (can be fitted only in conjunction with ML-11) ML-10
Central locking system for one additional door/tailgate ML-11
Radio r
emote conr
ols for specifi
c vehicles
MT-150-WAECO2
Accessories
