Instructions / Assembly

Technical Data PSG2 500
30 wc_td000252gb.fm
6.2 Operating Specifications (60 Hz)
* The weight (mass) given above is the operating weight of the pump itself, not including the cable
assembly.
Model: PSG2 500 BOM: 0620412
Pump
Electric power
V/Ph/Hz
110/1/60
Rated current
A
6.1
Starting
method
Capacitor-run
Discharge
mm (in.)
50 (2-inch NPT)
Output
kW (Hp)
0.48 (2/3)
Max. head
m (ft.)
12 (39.5)
Max. capacity
L/min
(GPM)
240 (62)
Max. pressure
kg/cm
2
(psi)
1.19 (17)
Solid size
capacity
mm (in.)
6 (0.2)
Weight*
Kg (lbs.)
10.5 (23)
