Maintenance G 50/G 70/G 85
wc_tx000484gb.fm 62
4.12 G 50/G 70 Engine Wiring
Engine
Wires
BOM Revision See
Graphic:
Revision
See
Graphic:
Rev. See
Graphic:
Revision
See
Graphic:
0009366 123 & higher wc_gr004613 109-122 wc_gr003218 108 wc_gr003172
107 & lower
wc_gr002615
0009367 124 & higher wc_gr004613 110-123 wc_gr003218 109 wc_gr003172
108 & lower
wc_gr002615
0009467 131 & higher wc_gr004613 112-130 wc_gr003218 111 wc_gr003172
110 & lower
wc_gr002615
0009468 133 & higher wc_gr004613 114-132 wc_gr003218 113 wc_gr003172
112 & lower
wc_gr002615
0620001 127 & higher wc_gr004613 109-126 wc_gr003218 108 wc_gr003172
107 & lower
wc_gr002615
0620002 129 & higher wc_gr004613 110-128 wc_gr003218 109 wc_gr003172
108 & lower
wc_gr002615
Ref. Description Ref. Description
1 Safety interlock switch 12 Plug 2 - engine start outputs
2 Mechanical lugs 13 Run/off/auto switch
3 Main circuit breaker 14 Battery
4 Shunt 15 10A fuse
5 Emergency stop switch 16 Starter relay
6 Engine control module 17 Starter
7 Plug 1 - engine sender inputs 18 Alternator
8 Remote start contacts 19 Terminal block
9 Fuel level sender 20 Magnetic pickup
10 Intake heater 21 Oil pressure sender
11 Intake heater relay 22 Water temperature sender
Ref. Description Ref. Description
17 Battery + 61 E-Stop
18 Battery + 62 Fuel level
53 Battery + 63 Crank
54 Speed sensor 64 Run/Fuel
56 Cold crank delay 65 Preheat
57 Water temperature 73 Remote annunciator
59 Battery - 75 Remote annunciator
60 Remote start 87 Oil pressure
