ACCESSORIES: Fig. 2
1. Use a screw-driver to loosen the two screw at the back of the xture body.
2. Take out the front frame, then change the lens.
3. To install cross louver or snoot, use the clips around the front frame to fasten them directly.
FIG.2
INSTALLATION INSTRUCTION
Exterminator II - LED Monopoint
MO-1052
Screw
LENS-25-SNOOT
LENS-25P-CRL
Front Frame
LENS-25
Aligning the Reector (Fig. 3)
Before putting the accessory assembly back to the xture, make sure to align the reector properly as shown in Fig. 3.
Fig. 3
Fix the reector on the LED
holder by twisting clockwise.
LED holder
