Data Sheet

Packaging Specification - Tape and Reel: [mm]
E1
F
E2
W
A0
B0
D1
P1
D0
P2
P0
T1
T2
T
K0
No Component
min. 160mm
Components No Component
min. 100mm
Cover Tape
min. 400mm
Top Cover
Tape
Carrier Tape
Cover Tape
End
Start
Feeding direction
A
A
packaging is reffered to the international standard IEC 60286-3:2013
A0 B0 W T T1 T2 K0 P0 P1 P2 D0 D1 E1 E2 F Tape Type 2a VPE / packaging unit
tolerance typ. typ. +0,3/ -0,1 ref. max. typ. typ. ±0,1 ±0,1 ±0,1 +0,1/ -0,0 min. ±0,1 min. ±0,1 pcs.
size xxx 16,0 0,1 4,0 2,0 1,5 1,5 1,75 14,25 7,5 Polystyrene xxx
1 6 5 ° - 1 8 0 °
Pull-of force
Tape width
16 mm
0,1 N - 1,3 N
B
D
C
A
N
W3
W2
W1
close to center
A B C D N W1 W2 W3 W3
Tolerance ± 2,0 min. min. min. min. + 2,0 max. min. max.
Tape width 16 mm 178,00 1,50 12,80 20,20 50,00 16,40 22,40 15,90 19,40
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. [phone] - 0
www.we-online.com
[e-mail]
CREATED CHECKED GENERAL TOLERANCE PROJECTION
METHOD
KaS SBa DIN ISO 2768-1m
DESCRIPTION
WE-SLM SMD Common Mode Line
Filter
ORDER CODE
744242510
REVISION STATUS DATE (YYYY-MM-DD) BUSINESS UNIT PAGE
004.010 Valid 2015-08-06 eiSos 3/6
This electronic component has been designed and developed for usage in general electronic equipment only. This product is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death, unless the parties have executed an agreement specifically governing such use. Moreover Würth Elektronik eiSos GmbH
& Co KG products are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc.. Würth Elektronik eiSos GmbH & Co KG must be informed about the intent of such usage before the design-in stage. In addition, sufficient reliability evaluation checks for safety
must be performed on every electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
