Specifications

10
The files
The sterilization data is saved on files with .TXT format and can be opened, viewed and printed by means of a
standard text editor. The files are saved with a read-only attribute.
Control code
At the end of the file a control code is included in order to allow the user to check the authenticity of the content.
The control code can be checked by W&H Sterilization.
The control code contains some additional information.
Example:
W&H O.D.Code 00-EC6FF-F62333696D4AD51A
W&H O.D.Code 0 0 - EC6FF - F62333696D4AD51A
1 2 3 4 5
1: W&H Original Data Code
2: Lisa log 64 internal programme
3: Upgrade loader release
4: Resuming code of the Lisa log 64 status (for W&H service)
5: Control code for the file content authenticity check
File name
The file names summarize the main information contained in the file according to the following structure.
File name example:
040128 28-01-04 08_41_22 A99 22E02-0095 01898 B&D _ HELIX TEST .txt
The file name is made up of the following information:
040128 28-01-04 08_41_22 A99 22 E 02-0095 01898 B&D _ HELIX TEST .txt
1 2 3 4 5 6 7 8 9 10
1: Date of the cycle: format YYMMDD in order to save the files chronologically:
YY last digits of the year
MM month
DD day
2: Date of the cycle: same format used by the sterilizer:
DD-MM-YY for EU versions
YY-MM-DD for JP versions
MM-DD-YY for US versions
3: Time of the cycle: same format used by the sterilizer:
HH-MM-SS for EU and JP versions
HH-MM-AM/PM for US versions
4: Alarm: (only in case of report with alarm)
with format AXX, where:
XX identifies the alarm code detected by the sterilizer
5: Model of the sterilizer:
17 LISA MB17 sterilizer
22 LISA MB22 sterilizer
6: Sterilizer programme release
E EU version
U US version
J JP version
7: Sterilizer Serial Number
8: Sterilizer cycle number
9: Cycle type
10: File name extension
WARNING:
The file name does not include forbidden characters \ / : * ? “ < > | as they violate the rules for the file
name generation. All forbidden characters are replaced by the character “_” (underscore). For example,
the file name B&D / HELIX is converted to B&D _ HELIX.
All data forming the file name are obtained directly from the print report and maintain the language used
on the sterilizer.
W&H STERILIZATION
LISA MB 22 EU 7.1
----------------------------------------
Dr.
SN. : 02-0095
----------------------------------------
Data : 28-01-04 08:13:57
Cycle : B&D / HELIX TEST
Number : 01898
----------------------------------------
PHASE TIME Temp C P Bar
Start 00:00 050.0 -0.03
PV1 05:25 05:25 050.0 -0.96
PP1 05:28 00:03 050.0 -0.67
………
…….
LEV 27:24 00:30 104.1 -0.03
----------------------------------------
END 27:24 104.1 -0.03
----------------------------------------
Data : 28-01-04 08:41:22
STERIL LOAD
===============
----------------------------------------
W&H O.D.Code 00-EC6FF-F62333696D4AD51A
PV2 06:39 01:11 057.6 -0.85
PP2 06:59 00:20 079.4 +0.07
PV3 08:01 01:02 069.3 -0.75
PP3 08:05 00:04 080.1 -0.43
----------------------------------------
A99 PHASE: PP3
----------------------------------------
5 6
7
9
8
1 2
3
4
