Specifications

9
English
Led
Memory Status St-by
MEANING
Off Stand-by status or power supply is missing.
Green
steady
OK – the data can be saved on the memory card
Red/Green
blinking
OK – the data can be saved, but the remaining memory capacity is less
than 50 cycles. Transfer the data onto your PC and insert a new one. It is
also possible to erase data from the previous one and re-use it.
Red
blinking
Impossible to save data – cable disconnected.
Red steady Impossible to save data– see Memory LED status.
Orange
blinking
Off
Warning: the last file saved does not contain a complete data cycle.
Check the parallel cable and perform a reprint (see page 7).
Note: The signalling continues until a complete file is saved; during a
cycle this signalling does not mean that there is an abnormality.
Off
With at least one LED on, the recorder is OK.
With all the LEDs off, no power supply
Off
Off
Yellow OK – Stand-by status
Orange Orange Off
Power supply problems. Check the cable connections (Connect and
disconnect).
If the problem remains, Lisa log 64 or the power supply may be damaged
– call for service.
Note: When Lisa log 64 and a printer (via a special adaptor) are used
at the same time and the printer is turned on, the signalling may
remain on even if the power supply is not connected to the Lisa
log 64.
Orange Orange Yellow Device not functioning (try to turn it off and then back on)
ACOUSTIC SIGNALING
Signaling Description
4 beeps
every 15
minutes
CABLE DISCONNECTED
The parallel cable is disconnected. If a cycle is launched the data will not be saved. Check the
connection between the sterilizer and Lisa log 64.
3 beeps at the
beginning of
the cycle
MEMORY NEARLY FULL
It is possible to save data, but the remaining memory capacity is less than 50 cycles. Transfer
the data onto your PC and insert a new one. It is also possible to erase data from the previous
one and re-use it.
3 beeps each
time the data
is received
MEMORY FULL, MISSING or FAILED
Impossible to save data.
Even if the memory card is full, Lisa log 64 is able to memorize a complete sterilization cycle.
Insert an empty card only at the end of the sterilization cycle.
CAUTION:
If other cycles are started the new received data could be lost. Transfer the data onto
your PC and insert a new one. It is also possible to erase data from the previous one
and re-use it.
