User Manual

Power Amplifier Serial I/F Spec.
5 Version 1.62
Description No. of
Bits
Definition Read/Write
Temperature 8 0 = 0C
255 = -1C
206 = -50C
100 = +100C
Read only
Forward Power 8 0 = 0 Watts
1 = 1 Watts
255 = 255 Watts
Read only
Reflected Power 8 0 = 0 Watts
1 = 1 Watts
255 = 255 Watts
Read only
DC Supply Voltage 8 0 = 0 Volts
255 = 30V
Read only
DC Supply Current 8 0 = 0 Amps
255 = 40 amps
Read only
Fan Fail Alarm 1 0 = Normal, 1 = Alarm Occurred Read only
Amplifier Online 1 0= offline, 1=enabled Read/Write
Amplifier Reset 1 0 = Normal, 1 = Reset Occurred Read/Write
Reverse Power
Shutdown
1 0 = Normal, 1 = Shutdown Occurred Read/Write
Amplifier Overdrive
Alarm
1 0 = Normal, 1 = Alarm Occurred Read/Write
Thermal Alarm 1 0 = Normal, 1 = Alarm Occurred Read/Write
Amplifier Overdrive
Shutdown
1 0 = Normal, 1 = Shutdown Occurred Read/Write
Thermal Alarm
Shutdown
1 0 = Normal, 1 = Shutdown Occurred Read/Write
Phase Control 8 -128 = -20 degrees min (in 40 steps)
0 = 0 degrees
+127 = +20 degrees min (in 40 steps)
Write Only
Attenuation Level 8 0 = -2 dB min (in 40 steps)
63 = No attenuation
127 = +2 dB min (in 40 steps)
Write Only
Serial Number 256 Read only
Table 2-1
2.2 Non-volatile read/write
In addition, the Power Amplifier contains 256 bytes of non-volatile read/write memory for
storing phase control and attenuation levels for various channel frequencies. The manufacturer
will be responsible for initializing correct attenuation & phase values for all frequencies, as well
as model and version numbers.
The memory content and locations are defined in Table 2-2:
