Rear Panel Overview
The following table gives the connector symbols printed on the back
panel and corresponding external cable connection.
Connector Symbol Connection Cable
IN power socket AC Power cord
OUT power socket Monitor Power cord
Monitor Video
PS/2 Keyboard
PS/2 Mouse
10/100Base-T
Serial COM1
Serial COM2
Parallel Printer
16 Bit Stereo line output (Pro / Netica)
Microphone input (Pro / Netica)
