Stereo Speaker System User’s Manual 2013 © VTech Printed in China 91-009656-000 US
INTRODUCTION Get better stereo sound out of your child’s InnoTab® Learning Tablet with the InnoTab® Stereo Speaker System! Just plug the audio cable into the InnoTab’s headphone jack, and watch videos, play games or listen to MP3 music with stereo quality sound! Compatible with all InnoTab® Learning Tablets. Note: Not a docking station - does not charge the InnoTab®.
PRODUCT FEATURES Volume Control On/Off Indicator Power Button Stand Audio Cable AC/DC Adaptor Jack Battery Compartment FEATURES ACTION Power Button Volume Control On/Off Indicator Stand AC/DC Adaptor Jack Press this button to turn the unit on or off. Turn the knob to adjust the volume. This light shows if the speakers are on or off. Use the stand to hold your InnoTab®. Use this to connect an AC/DC adaptor (sold separately). Insert 4 AA batteries here.
Assembling the Stereo Speaker System 1. Rotate the speakers together as shown in the image below. 2. Place the speakers on top of the stand and push down until you hear a click. USING THE SPEAKERS WITH YOUR INNOTAB 1. Insert 4 AA batteries or plug an AC adaptor into the jack in the back of the unit. 2. Plug the Audio Cable into the headphone jack of your InnoTab®. 3.
Battery Installation • Make sure the speakers are turned off. • Open the battery door on the back of the speaker. • Insert 4 AA batteries as shown in image 2. • Make sure to replace the battery cover. Image 1 Image 2 BATTERY NOTICE • Use only batteries of the same or equivalent type as recommended. • Do not mix different types of batteries: alkaline, standard (carbon-zinc) or rechargeable (Ni-Cd, Ni-MH), or new and used batteries. • Do not use damaged batteries.
AC Adaptor • Using a VTech® adaptor (AC/DC 7.5 V) is recommended. • Make sure the tablet is turned off. • Plug the adaptor (sold separately) into the AC adaptor jack on the back of the InnoTab® Stereo Speaker System. • Plug the adaptor into a wall socket. NOTE: The use of an adaptor will override the batteries. When the toy is not going to be used for an extended period of time, unplug the adaptor.
TroubleShooting Problem No sound is coming out of the speakers. Solution 1. Make sure that batteries are installed or an AC adaptor is plugged in. 2. Check the indicator light and confirm that the speakers are on. 3. Adjust the volume control. 4. Make sure the audio cable is fully plugged in to the InnoTab®, and the InnoTab® is on. Increase the volume on the InnoTab®.
COMPANY : VTech® Electronics North America, L.L.C. Address: 1156 W. Shure Drive, Suite 200, Arlington Heights, IL 60004 USA TEL NO.: 1-800-521-2010 in the U.S. or 1-877-352-8697 in Canada Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
