Appendix
Technical specications
Appendix
SIP contemporary cordless 1-line/2-line - CTM-S2411/CTM-S2421
Power requirement 2.4V Ni-MH battery
Frequency control Crystal controlled PLL synthesizer
Transmit frequency 1921.536-1928.448 MHz
Channels 5
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to
environmental conditions at the time of use.
Message waiting signal From SIP server
Speed Dial memory Telephone base: up to 11 memory locations; up to 32 digits
Size Telephone base: 8.03 x 6.06 x 3.78 in (204 x 154 x 96 mm)
Handset: 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)
SIP contemporary cordless 1-line/2-line accessory Petite - CTM-S241P/CTM-S242P
Frequency Control Crystal controlled PLL synthesizer
Transmit frequency 1921.536-1928.448 MHz
Channels 5
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to
environmental conditions at the time of use.
Power requirement 5.1V DC @1.3 A
USB port Provide charging current up to 1A
Speed Dial memory Accessory Petite: up to 11 memory locations; up to 32 digits
Size Accessory Petite: 8.03 x 6.06 x 3.78 in (204 x 154 x 96 mm)
Corded handset: 8.39 x 1.89 x 1.65 in (213 x 48 x 42 mm)
SIP contemporary charging base - C4300
Power requirement PoE class 2 powered (48V)
Size 8.11 x 3.70 x 2.87 in (206 x 94 x 73 mm)
SIP contemporary charging stand - C4310
Power requirement PoE class 2 powered (48V)
Size 3.78 x 2.80 x 4.29 in (96 x 71 x 109 mm)
SIP contemporary charging stand - C4011
Power requirement 6V DC @450mA
Size 3.78 x 2.80 x 4.29 in (96 x 71 x 109 mm)
