48
Accessory Petite installation
The telephone can be adapted to desktop use or mounted on a standard telephone wall plate.
Installation option - desktop position
Turn the accessory Petite over with the bottom side facing up. Connect the small end of the power adapter cord to the
accessory Petite.
Position the mounting bracket as shown. Insert the two small tabs of the mounting bracket into the lower slots on the accessory
Petite. Then press the large tab on the mounting bracket and rmly push it into the upper groove on the accessory Petite.
Install the accessory Petite as shown below. Then connect the coiled handset cord to the accessory Petite.
1.
2.
3.
Installation
SIP contemporary cordless 1-line/2-line accessory Petite - CTM-S241P/CTM-S242P
Power jack
Power adapter
Electrical outlet not
controlled by a wall switch
Power cord
