User's Manual

Prog.
No.
Function Selection Options Comments
1
Display
brightness
A
7
~
1
= Automatic
= brightest manual setting
= dimmest manual setting
2
Hour display
mode
12
24
= 12 hour display
= 24 hour display
3
Synchronisation
mode
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
= Stand-alone operation
= one second uni-polar impulse
= one second alternate polarity impulse
= half minute uni-polar impulse
= half minute alternate polarity impulse
= one minute uni-polar impulse
= one minute alternate polarity impulse
= W482 time code
= MSF time code - BST display
= MSF time code - UTC(GMT) display
= DCF time code - CET display
= DCF time code - UTC display
= IRIG-B time code
= afnor NF S 87- 500 time code
= EBU/SMPTE time code
- refer to page 11 = Leitch (TM) format
= EBU/SMPTE time code
- refer to page 11
= Slave to local 400A master
= RS232/RS485 serial ascii format (1)
= RS232/RS485 serial ascii format (2)
= RS232/RS485 serial ascii format (6)
= H310 serial time code
= Mobaline® time code
= GPS time code
Uses internal crystal
6-24v
6-24v
6-24v
6-24v
6-24v
6-24v
Code from 482 or 4850
series master clock
requires appropriate
484 series radio time code
receiver
requires 404.I interface,
- set year manually.
requires 404.I interface
requires 404.E interface
requires 404.E interface
requires 404.2 (RS232)
or 404.4 (RS485) interface
refer to 488GPS manual
-for further information
4
Run mode 1
1
2
= blank if code fails
= display last message for -
= setable to time and date, continue to
count with colons flashing when not
synchronised
W482, H310, Mobaline &
GPS synchronisation only.
EBU, IRIG and serial ASCII
codes only.
7
Programmable Options - 1
Issue 2.2
