mounting rose & upper
tube supplied by customer
20mm tube
50mm square
connecting section
suspended ceiling
20mm support tube
painted to
BS0055/RAl9010
single or double
sided clock
mains & data cable
Case style .SS. - ’X’ = 58
Case style .DS. - ’X’ = 120
’X’
Mounting Details - Ceiling Suspended Cases
