User's Manual

START - HOLD - STOP
M3 clearance hole
CSW
RESET
102.0 72.088.0
to clock
12.0
22.0 22.0
3 core cable
27.0
54.0
44.0
C
SW
START - HOLD - STOP
RESET
SWC
Time-of-day display selected
Stopwatch display selected
Stopwatch start, hold or stop function selected
Stopwatch time count stopped Stopwatch time count stopped and set to
pre-programmed countdown start time value
First display of stopwatch function, countdown
or
and reset to zero
402A
Switch Control Unit Details
Control switch functions in normal operating mode
Refer to page 16 for further
information on stopwatch start, stop
and display hold functions and
programming
Refer to the following page for
further information on stopwatch
function, countdown start time
and time-of-day programming
start time and time-of-day programming
Panel
cut-out
15
402A Stopwatch Controller - 3
