User's Manual

400A series clocks may be programmed to synchronise to EBU/SMPTE time code signals when the optional
404.E interface is fitted. Calendar clocks may be synchronised to one of two date formats. Format 1 (*)
is desgined to work with other manufacturers' displays - eg Leitch (TM) whereas Format 2 (**) displays time/date on a
video signal in an understandable order. Both formts work with V-401A/V-420A/V-490A Time Displays (ie no date)
Application 401, 420 & 490 Clocks
Calendar Clocks
V-400A Clock
program setting
Prog. 3, Opt. 15 Prog. 3, Opt. 16
Prog. 3, Opt 15 * Prog. 3, Opt 16 **
Master Clock
program settings
Prog. 17, Opt. ‘0’
Prog. 18, Opt. ‘0’
Not applicable
414 Timer only
Prog. 17, Opt. ‘1’
Prog. 18, Opt. ‘0’
Prog. 17, Opt. ‘1’
Prog. 18, Opt. ‘1’
Bits Data Bit Content
0 - 3 Frame No. units Frame No. units Frame No. units Frame No. units
4 - 7 Unused bits Unused bits Unused bits Status bits
8 - 9 Frame No. tens Frame No. tens Frame No. tens Frame No. tens
10 - 11 Unused bits Unused bits Unused bits Unused bits
12 - 15 Days Units Unused bits
16 - 19 Seconds units Seconds units Seconds units Seconds units
20 - 23 Unused bits Unused bits Months units Years units
24 - 26 Seconds tens Seconds tens Seconds tens Seconds tens
27 Unused bits Unused bits Unused bit Unused bit
28 - 29 Days tens Years tens
30 Months tens
31 Unused bit
32 - 35 Minutes units Minutes units Minutes units Minutes units
36 - 39 Unused bits Unused bits Unused bits Months units
40 - 42 Minutes tens Minutes tens Minutes tens Minutes tens
43 Unused bits Unused bits Unused bit Unused bit
44 - 45 Years units Months tens
46 - 47 Unused bits Unused bits
48 - 51 Hours units Hours units Hours units Hours units
52 - 55 Unused bits Unused bits Unused bits Days units
56 - 57 Hours tens Hours tens Hours tens Hours tens
58 - 59 Unused bits 414 Control bits Unused bits Unused bits
60 - 62 Unused bits Years tens Days tens
63 Unused bits
64 - 79 Sync word Sync word Sync word Sync word
11
EBU/SMPTE Code Formats
Issue 2.2
