Voltsoft User Manual Version 2.8
91
"CIRCULAR LOGGING": Data logger starts recording
immediately and circularly. The newest data overwrites
the oldest data. It stops recording/logging once the
battery is depleted or “CIRCULAR LOGGING” has been
replaced by another “RECORD START CONDITION”
during configuration.
4
Stop Style
"NONE": No stop condition is specified. Data logger
stops recording based on the "RECORD START
CONDITION" setting.
"STOP BUTTON": Data logger stops recording after
holding button ENTER pressed for few seconds.
"AFTER PDF CREATED": Data logger stops recording
after PDF report is generated.
5
Start Time
Define date and time when to start recording data.
6
Stop Time
Define date and time when to stop recording data.
7
Start Delay Minutes
Define delay time of immediate start of recording.
8
Sampling Rate
Define how frequent the data logger measures and
records data in “SECONDS”, “MINUTES” or “HOURS”.
9
Recording Time
This value is automatically calculated based on the
sampling rate and cannot be set by the user.
10
LED Flash Interval
Select how fast the LED control lights (2,3) shall flash.
Choose an interval of 5, 10, 15, 20, 25 or 30 seconds.
11
Enable Display
Remove the checkmark from the check box to turn off
the LC display, or check the checkbox to turn on the LC
display.
12
Enable LED Alarm
The LED alarm indicates when a measured value is
outside the defined range.
To disable the LED alarm, remove the checkmark in the
checkbox.
To enable the LED alarm, check the checkbox .
13
Limit Pause Function
During recording, the limit alarm can be suspended.
Select “ENABLE” or “DISABLE” to enable/disable the
pause function.
Pause function will not stop the recording.
14
Low Alarm / High Alarm
Select parameter(s) by checking parameter checkboxes
and specify the low and high alarm in numbers.
For air pressure, choose the desired unit from the drop
menu (DL-220THP only).
15
Language
Choose the language, in which the PDF report shall be
shown, from the selection box.
16
PDF File Name
Click on "INSERT NAME" to define the pattern of the file
name.
A new window "PLEASE CHOOSE THE NAME PATTERN
BELOW" opens. Choose the required elements
(OWNER/SERIAL
ID/MODELNAME/DATE/TIME/LOCATION) and their
order.
Up to 6 elements can be chosen. Chosen elements
appear in the field "FILE NAME".
Press "CLEAR" to delete all chosen elements. The field
