9. Initial operation
Do not exceed the maximum permitted input values.
Before measuring, check the measuring device for damage such as cuts, cracks or squeezing. A
defective device must not be used. Mortal danger!
Beforeusingforthersttime,theenclosedbufferbatterybeinsertedforthetimeanddate.Insertingandchangingthe
battery can be found in Section „Maintenance and Cleaning“.
After inserting the buffer battery, connect the measuring device in a standard protection socket. The measuring device
is ready for programming or operation.
10. Basic settings
Aftertherstuse,someparametersmustbepresettoallowacorrectdisplay.Youcanreachthismodebypressing
the „MODE“ and „Continue“ keys (7) for at least 5 seconds simultaneously. This key combination also deletes the
measurement value memory in the device (reset). Hold down on both buttons, keeping them pressed down, until all
symbols are shown in the display. After releasing the keys, the menu item “Select device ID” opens.
Save and delete the data memory before every measurement series.
a) Select ID device
This equipment ID number allows you to administer up to 10 electrical users on one meter unit. In the adjustment
modetheIDnumberblinksintherightupperdisplay.Choosethedesiredidenticationnumber(ID0-9withthebut-
tons“min”(3)and“max”(4)andconrmyourchoicewiththebutton“MODE”(5).Themachinewillthensendyou
automatically to the next mode, “time setting.”
The device ID is required to allocate the measurement data in the software. It must correspond to the currently re-
corded ID when reading data in the software. Only one device ID can be recorded. Once data transfer is complete,
another ID can be selected to differentiate the data for different users in the software.
b) Time settings
Firstyouselectthethedesiredtimeformat(12/24-hsystem)withthetwoarrowkeys(3and4)andconrmyour
selection with the „MODE“ key (5).
Select the date format with the two arrow keys (3 and 4). Available are:
dd.mm.yyyy for day/month and year or
mm.dd.yyyy for month/day and year
Conrmtheselectionbypressingthe“MODE“(5)key.Youwillautomaticallyreachthenextmode.
Thehoursdisplayofthetimeashes.Setthecorrecttimewiththearrowkeys(3and4).Afterenteringthehours,you
reach the minute input by pressing the „Continue“ arrow key (7). Repeat these steps until you have set day, month
and year.
Conrmyoursettingsintheyearmodebypressingthe“MODE“(5)key.Thetimestartstorunandyouautomatically
reach the next mode.
