8. Display indications and symbols
▲ Upsymbol
▼ Downsymbol
► Continuesymbol
MODE Mode switching (measurement display)
max/min Maximum/minimum value display
MEM 0 - 99% Remaining size of the internal memory
ID 0 - 9 Consumer number, up to 10 consumers can be managed
Power1/2 Display of current values
Consumption Display of the recording data of electric consumption
Total Total value
cost1/2 Cost display for tariff 1 or 2
History today Display of the recorded data for today or up to 9 days in the past
REC time h Recording time in hours, since the measuring device was plugged in
ON time h Actual operating time of electric consumption, e.g. for fridges
Forecast Calculative preview
cost/m Cost forecast per month (for tariffs 1 or 2)
cost/y Cost forecast per year (for tariffs 1 or 2)
Time Display of time and date
Symbol for connected SDHC card
V Volt (unit of electric potential)
A ampere (unit of electric current)
Hz Hertz (unit of frequency)
W Watt (unit of effective power)
VA Volt ampere (unit of output, without reference to the performance factor)
cosPHI Performance factor (factor of phase shift)
kWh Kilowatt hours (unit of electrical power)
Symbol for capacity load
Symbol for inductive burden
