5. Product description
The Energy Logger 4000 shows all data established on a concise display. The following displays are possible:
• Clamping (V), electricity (A) and frequency (Hz), user type (load, burden/capacity load)
• Effective power (W), output (VA) and performance factor (cosPHI)
• Min/max recording of V, A, Hz, W, VA and cosPHI
• Overall consumption (kWh), usage costs (cost) tariffs 1 and 2
• Daily consumption (kWh, cost1/2), retroactively up to 9 days
• Recording time (REC time) and operating time (ON time)
• Cost preview per month and year
• Time and date display
• Display of the remaining memory size (MEM in %)
The measurement device can be used in the hoggy and professional area, but must not be used for balanc-
ing purposes.
Priortoworkingwiththemeasuringdevice,yoursthavetoinserttheenclosedbatteries.
Insert the battery as described in Section „Cleaning and Maintenance“. To buffer time and date, a lithium cell type
CR1620 is required. These are supplied with the device.
