User manual

55
DC voltage
Range Resolution Accuracy*
400.0 mV 0.1 mV ±(0.8% + 6)
4.000 V 0.001 V
±(1.2% + 5)40.00 V 0.01 V
400.0 V 0.1 V
600 V 1 V ±(1.5% + 3)
600 V overload protection; Impedance: 10 MΩ
* Accuracy: 40 - 60% of the measurement range; +1% outside of this range
Temperature
Range Resolution Accuracy*
-20.0 to +760.0 °C 0.1 °C ±(4% + 5 °C)
-4.0 to +1400.0 °F 0.1 °F ±(4% + 5 °C)
* Without sensor tolerance
* Accuracy: 40 - 60% of the measurement range; +1% outside of this range
Resistance
Range Resolution Accuracy*
400.0 Ω 0.1 Ω ±(1.5% + 6)
4.000 kΩ 0.001 KΩ
±(1.8% + 4)40.00 KΩ 0.01 KΩ
400.0 KΩ 0.1 KΩ
4.000 MΩ 0.001 MΩ ±(2.8% + 5)
40.00 MΩ 0.01 MΩ ±(2.8% + 10)
Overload protection 600 V; Measuring voltage: Approx. 0.5 V
*Accuracy: 40 - 60% of the measurement range; +1% outside of this range
