CENTER INTERFACE PROTOCOL INFORMATION

TO: CONRAD

B/N CONRAD MODEL NO CENTER MODEL NO PROTOCOL VERSION

100356 VOLTCRAFT 300K CENTER 300 300-303Rs232Protocol

100357 VOLTCRAFT 302KJ/KJ202 CENTER 303 300-303Rs232Protocol

120585 VOLTCRAFT K204 CENTER 304 304-309Rs232Protocol

100567 VOLTCRAFT K204 CENTER 309 304-309Rs232Protocol

100359 VOLTCRAFT K202 CENTER 306 305-306Rs232Protocol

Summary of content (7 pages)

PAGE 1
CENTER INTERFACE PROTOCOL INFORMATION TO: CONRAD B/N CONRAD MODEL NO CENTER MODEL NO PROTOCOL VERSION 100356 VOLTCRAFT 300K CENTER 300 300-303Rs232Protocol 100357 VOLTCRAFT 302KJ/KJ202 CENTER 303 300-303Rs232Protocol 120585 VOLTCRAFT K204 CENTER 304 304-309Rs232Protocol 100567 VOLTCRAFT K204 CENTER 309 304-309Rs232Protocol 100359 VOLTCRAFT K202 CENTER 306 305-306Rs232Protocol
PAGE 2
300,301,302,303-Rs232 protocol RS232 K(ASC 4BH) H(ASC 48H) T(ASC 54H) function Ask for model No.
PAGE 3
bit1:1->main window value is minus, 0->main window value is plus. bit2:1->4th byte and 5th byte represent #### 0-> 4th byte and 5th byte represent ###.# bit3:1->sub window value is OL 0->not OL bit4:1->sub window value is minus, 0->sub window value is plus. bit5:1->6th byte and 7th byte represent #### 0-> 6th byte and 7th byte represent ###.
PAGE 4
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 no use no use no use Time unit no use X1_X10 minus OL bit0:1->main window value is OL 0->not OL bit1:1->main window value is minus, 0->main window value is plus. bit2:1->4th byte and 5th byte represent #### 0-> 4th byte and 5th byte represent ###.# bit4:1->sub window value is MM:SS, 0-> sub window value is HH:MM 4th 5th 6th 7th BYTE:first two BCD code of main window value. BYTE:last two BCD code of main window value BYTE:first two BCD code of sub window value.
PAGE 5
300,301,302,303-Rs232 protocol Baudrate : 9600 Parity: none Data bits : 8 Stop bits : 1 Command list: RS232 K(ASC 4BH) H(ASC 48H) T(ASC 54H) M(ASC 4DH) N(ASC 4EH) R(ASC 52H) C(ASC 43H) A(ASC 41H) function Ask for model No.
PAGE 6
bit5:1- HOLD 0->not HOLD bit6:1->LOW BATTERY 0->BATTERY NORMAL bit7:1->C 0->F 3nd BYTE: bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 point minus OL point minus OL bit0:1->main window value is OL 0->not OL bit1:1->main window value is minus, 0->main window value is plus. bit2:1->4th byte and 5th byte represent #### 0-> 4th byte and 5th byte represent ###.# bit3:1->sub window value is OL 0->not OL bit4:1->sub window value is minus, 0->sub window value is plus.
PAGE 7
bit3:1->0->K TYPE 1->J TYPE(300 only has K type) bit4:1->REL bit5:1- HOLD 0->not HOLD bit6:1->LOW BATTERY 0->BATTERY NORMAL bit7:1->C 0->F 3th BYTE: bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 no use no use no use Time unit no use X1_X10 minus OL bit0:1->main window value is OL 0->not OL bit1:1->main window value is minus, 0->main window value is plus. bit2:1->4th byte and 5th byte represent #### 0-> 4th byte and 5th byte represent ###.
