• First,disconnectthedeviceconnectedtothechargingoutputofthepowerbank.
Itisnotpossibletousethechargingoutputandtochargethepowerbankatthesame
time.
• NowconnectbothUSB-AplugsoftheUSB-YcableprovidedwithyourPCoraUSBhub
withitsownpoweradapter.ThecurrentfrombothUSBplugsisadded(500mAeachfor
USB2.0)sothatachargingprocessofthepowerbankispossible.
DonotuseUSBportsofe.g.akeyboardoraUSBhubwithoutitsownpoweradapter
asthecurrentprovidedhereisnotsufcient.
• Then,connectthemicroUSBplugoftheUSB-YcablewiththemicroUSBsocketofthe
powerbank.
 
 AlwaysconnectthetwoUSB-AplugsoftheUSB-Ycableprovidedwithyour
PCoraUSBhubwithitsownpoweradapter,andconnectthemicroUSBplug
withthecorrespondingsocketofthepowerbank.
• Duringthechargingprocess,theLEDsindicatetherespectivecharginglevel.
 Here,thepermanentlylitLEDsindicatethecharginglevel(1LEDpermanentlylit=battery
25%charged,2LEDs=50%,3LEDs=75%,4LEDs=100%)andashingLEDsindicate
thecontenttobecharged.
 Example:3LEDsarepermanentlylit,oneLEDashes:Thebatteryis75%rechargedand
theremaining25%arecurrentlycharged.
• Thechargingdurationisdependantonthecharginglevelofthebatteryandmaybeseveral
hours(forchargingdurationofacompletelyatbattery,seechapter“TechnicalData”).
• Oncethebuilt-inrechargeablebatteryisfullycharged,disconnectthemicroUSBplugfrom
thepowerbank.Thepowerbankisnowreadyforuse.

• First,disconnectthepowerbankfromthechargingcable,removethemicroUSBplugfrom
thepowerbank.
Itisnotpossibletousethechargingoutputsandtochargethepowerbankatthesame
time.
• Thepowerbankhastwochargingports;awhichasuitablemobiledevice(e.g.smartphone)
canbechargedateach.
Oneofthechargingportsprovidesachargingcurrentofmax.1A,theothercharging
portprovidesachargingcurrentofmax.2A.Payattentiontothelabellingnexttothe
respectivechargingport.
 Youcanusebothchargingportsatthesametime.
 ConnecttherespectiveUSB-Aporttoyourmobiledevice/smartphoneusingasuitable
cable.
• Presstheoperatingbuttonbrieytoswitchonthepowerbank.The4LEDsshowthe
presentchargelevelofthebuilt-inrechargeablebattery(1LED=25%,2LEDs=50%,
3LEDs=75%,4LEDs=100%).AsingleashingLEDindicatesthatthechargelevelis
below25%.
• Monitorthechargingprocess.Oncethemobiledevice/smartphoneisfullycharged(orthe
rechargeablebatteryofthepowerbankisempty),thepowerbankwillturnoff.
• Tostopchargingmanually,disconnectthecableconnectionbetweenyourmobiledevice/
smartphoneandthepowerbankbyunpluggingtheUSBplugofthecablefromtheUSB-A
portonthepowerbank.
 Thepowerbankswitchesoffautomaticallyafterafewseconds,theblueLEDsofthe
charginglevelindicatorgoout.

• Holddowntheoperatingbuttonforabout2secondstoswitchthewhiteLEDofthetorchon
oroff.
ThiswillalsoactivatetheLEDsofthecharginglevelindicator,seeaboveundera).
• WhenthewhiteLEDison,youcantogglebetweencontinuouslightandSOSashing
functionbypressingtheoperatingbutton.

Theproductdoesnotrequireanymaintenanceandshouldneverbedisassembledforany
reason.Therechargeablebatteryispermanentlyinstalledandcannotbereplaced.
Cleantheproductcarefully,e.g.withasoft,cleancloth.Dustcanbeeasilyremovedwitha
soft,cleanbrushandavacuumcleaner.
Neveruseaggressivecleaningagentsandnochemicalsatallforcleaning;thesecanlead
notonlytodiscolouration,butcanalsodamagetheproduct.

 Electronicdevicesarerecyclablematerialanddonotbelonginthehousehold
waste.
 Pleasedisposeofthedevice,whenitisnolongerofuse,accordingtocurrent
statutoryrequirements.

Charginginput......................................1xmicroUSBport
Inputvoltage/current.............................5V/DC,max.1A
Chargingoutput....................................2xUSBportoftypeA
Outputvoltage/current..........................Chargingoutput#1:5V/DC,max.1A
..............................................................Chargingoutput#2:5V/DC,max.2A
Internalrechargeablebattery................Lilon,3.7V,7800mAh
Chargingduration.................................approx.10hwithcompletelyemptyrechargeable
battery
Ambientconditions...............................Temperature-20°Cto+60°C,airhumidity30%to
80%relative,notcondensing
Dimensions(WxHxD).......................101x23x64mm
Weight..................................................188g
