User's Manual

Meets the MIL STD -810F specification for shock and vibration.
Drop Tested
In addition, the device has been tested to the following specifications:
• 25 drops from 5 feet, 10 additional drops from 6 feet onto polished concrete
• 10 drops at varying angles from 5 feet at -20° F (-29° C) onto polished concrete
100% condensingHumidity
IP67Enclosure Rating
T1 Specifications:Talkman T1
5.3 ounces (150 g) (with battery)Weight
100 mmLength
51.5 mmWidth
24 mmDepth
-1° to 50° C (30° to 122° F)Operating Temperature
-40° to 70° C (-40° to 158° F)Storage Temperature
The device is not designed to be repeatedly dropped. The device
has been tested to the following specifications:
Drop Tested
• 18 drops from 4 feet
5 to 95% non-condensingHumidity
IP54Enclosure Rating
Loading an Operator's Templates onto a Device
You need a device with a charged battery, headset, and any other equipment (belt, bar code reader) you are going to
use. You must be within radio range. Make sure the device is on or sleeping. The LED indicator should be either solid
green or blinking green (T5-series and T2-series) or solid green (T1).
1. Press the Operator button.
The device says "Current operator is operator name. Select menu item."
2. Press the + button or — button until the device says, "Change operator."
3. Press the Operator button.
4. The device says, "Please wait" and retrieves a list of operators and teams. Wait for the device to say, "Select team".
• If the device says "Current operator is (operator name). Change operator", skip to step 8.
