User's Manual

• If you insert a fully charged battery into a charger, the charger will analyze the battery's status and then "top
off" the battery's charge. During this process, the left LED indicator for that slot on the charger is red. It may
take several minutes for this process to complete, at which time both LED indicators for that slot turn green.
1. Make sure the battery charger is powered. The green LED indicator on the end of the battery charger should be lit.
2. Power off the headset by pressing and holding the Plus and Minus buttons on the earpiece for three seconds and then
remove the battery.
3. Hold the battery with its contacts to the bottom and the Vocollect logo facing toward you, and insert it into an empty
slot on the battery charger.
4. Press down on the battery until it snaps into place.
5. Make sure the battery is firmly in place and cannot be removed without pressing the battery release button.
Inserting a Battery into the SRX Wireless Headset
Important: Do not force the battery into the compartment. Doing so may result in damage to the battery or the
headset. If the battery does not snap easily into place, reposition the battery in the compartment and try again.
1. Make sure the battery is charged. A battery is fully charged and can be removed from the charger when the left and
right LED indicators for that slot on the charger are green.
2. Hold the headset with the battery compartment facing toward you.
3. Place the end of the battery with the contacts into the compartment first so that the contacts on the bottom of the
battery line up with the contacts in the compartment.
4. Press down on the battery until it snaps into place.
5. Make sure the battery is firmly in place and cannot be removed without pressing the battery release button.
Removing a Battery from an SRX Wireless Headset
Important: Do not remove the battery until the LED indicator on the headset is off.
1. Power off the headset by pressing and holding the Plus and Minus buttons on the earpiece for three seconds.
2. Hold the headset with the battery compartment facing toward you.
3. Pull the battery release button, located on the left side of the battery compartment, away from the battery until the
end of the battery pops up from the compartment.
4. Lift the battery out of the compartment.
Battery Warm-Up Time
If a battery has been used in a cold environment, it will not begin charging until it warms up sufficiently.
It will take approximately this amount of time to warm
up...
If the battery was being used at...
6 minutes-4°C (24.8°F)
10 minutes-10°C (14.0°F)
OpenTopic | Batteries | 59
