Removing a Battery from a Talkman T5-Series or T2-Series Device
Make sure the Talkman wearable computer is off.
Caution: Do not remove the battery until the LED indicator is off. If you remove the battery when the device is
on or sleeping, any data collected could be lost.
1. Hold the wearable computer in one hand with the battery compartment facing toward you.
2. Press the battery release button all the way down until the top of the battery pops up from the battery compartment.
Figure 29: Removing the Battery From a Device
3. Lift the battery out of the compartment.
Removing a Battery from a Talkman T1 Device
Make sure the Talkman wearable computer is off.
Caution: Do not remove the battery until the LED indicator is off. If you remove the battery when the device is
on or sleeping, any data collected could be lost.
1. Hold the wearable computer in one hand with the battery compartment facing toward you.
2. Push the battery release button up and pull the battery out.
Charging SRX Wireless Headset Batteries
Important: Once an SRX battery is placed in the charger, it must remain in the charger for a minimum of five
seconds. This allows the charger sufficient time to analyze the state of the battery. Removing the battery during
this five second interval may cause the LED indicator on the charger to display an incorrect battery status.
Important: Do not force the battery into the compartment. Doing so may result in damage to the battery or the
headset. If the battery does not snap easily into place, reposition the battery in the compartment and try again.
Note:
• A battery is fully charged and can be removed from the charger when the left and right LED indicators for that
slot on the charger are green.
