Table 5-12. Identification Mappings for VMWARE-VMINFO-MIB (Continued)
Variable ID Mapping Description
vmwFloppyEntry vmwFloppyTable 1
Identifies a single floppy device. May change across
system reboots.
vmwFdVmIdx vmwFloppyEntry 1
A number corresponding to the virtual machine’s index
in the vmwVmTable.
vmwFdIdx vmwFloppyEntry 2
Identifies a specific virtual floppy device.
vmwFdName vmwFloppyEntry 3
The file or device that this virtual floppy device is
connected to.
vmwFdConnected vmwFloppyEntry 4
Reports true if the floppy device is connected.
Virtual DVD or CD-ROM Variables
vmwCdromTable vmwVirtMachines 6
A table of DVD or CD-ROM drives for all virtual
machines in vmwVmTable.
vmwCdromEntry vmwCdromTable 1
Identifies a specific CD-ROM or DVD drive. May
change across system reboots.
vmwCdVmIdx vmwCdromEntry 1
A number corresponding to the virtual machine’s index
in the vmwVmTable.
vmwCdromIdx vmwCdromEntry 2
Identifies the specific DVD or CD-ROM drive.
vmwCdromName vmwCdromEntry 3
The file or device that the virtual DVD or CD-ROM
drive has been configured to use.
vmwCdromConnected vmwCdromEntry 4
Reports true the CD-ROM device is connected.
Virtual Machine Trap Variables
vmwVmID vmwTraps 101
Holds the same value as vmwVmVMID of the affected
virtual machine generating the trap, to allow polling of
the affected virtual machine in vmwVmTable.
vmwVmConfigFilePath vmwTraps 102
The configuration file of the virtual machine generating
the trap.
Table 5-13 lists the traps defined in VMWARE-VMINFO-MIB.mib. These traps were formely defined in VMWARE-TRAPS-
MIB.mib.
Table 5-13. Traps Defined in VMWARE-VMINFO-MIB
Trap ID Mapping Description
vmwVmPoweredOn vmwVmNotifications 1
This trap is sent when a virtual machine
is powered on from a suspended or
powered off state.
vmwVmPoweredOff vmwVmNotifications 2
This trap is sent when a virtual machine
is powered off.
vmwVmHBLost vmwVmNotifications 3
This trap is sent when a virtual machine
detects a loss in guest heartbeat.
VMware Tools must be installed in the
guest operating system in order for this
value to be valid.
vmwVmHBDetected vmwVmNotifications 4
This trap is sent when a virtual machine
detects or regains the guest heartbeat.
VMware Tools must be installed in the
guest operating system in order for this
value to be valid.
vmwVmSuspended vmwVmNotifications 5
This trap is sent when a virtual machine
is suspended.
