Table 5-12. Identification Mappings for VMWARE-VMINFO-MIB (Continued)
Variable ID Mapping Description
vmwVmVMID vmwVmEntry 7
An identification number assigned to running virtual
machines by the VMkernel. Powered-off virtual
machines to not have this ID.
vmwVmGuestState vmwVmEntry 8
The state of the guest operating system (on or off).
vmwVmCpus vmwVmEntry 9
The number of virtual CPUs assigned to this virtual
machine.
Virtual Machine HBA Variables
vmwVmHbaTable vmwVirtMachines 2
A table of HBAs visible to a virtual machine.
vmwVmHbaEntry vmwVmHbaTable 1
Record for a single HBA.
vmwHbaVmIdx vmwVmHbaEntry 1
A number corresponding to the virtual machine’s index
in the vmwVmTable.
vmwVmHbaIdx vmwVmHbaEntry 2
Uniquely identifies a given HBA in this VM. May
change across system reboots.
vmwHbaNum vmwVmHbaEntry 3
The name of the HBA as it appears in the virtual
machine settings.
vmwHbaVirtDev vmwVmHbaEntry 4
The HBA hardware being emulated to the guest
operating system.
vmwHbaTgtTable vmwVirtMachines 3
The table of all virtual disks configure for virtual
machines in vmwVmTable.
vmwHbaTgtEntry vmwHbaTgtTable 1
A record for a specific storage disk. May change across
reboots.
vmwHbaTgtVmIdx vmwHbaTgtEntry 1
A number corresponding to the virtual machine’s index
(vmwVmIdx) in the vmwVmTable.
vmwHbaTgtIdx vmwHbaTgtEntry 2
This value identifies a particular disk.
vmwHbaTgtNum vmwHbaTgtEntry 3
Identifies the disk as seen from the host bus controller.
Virtual Machine Network Variables
vmwVmNetTable vmwVirtMachines 4
A table of network adapters for all virtual machines in
vmwVmTable.
vmwVmNetEntry vmwVmNetTable 1
Identifies a unique network adapter in this table.
vmwVmNetVmIdx vmwVmNetEntry 1
A number corresponding to the virtual machine’s index
in the vmwVmTable.
vmwVmNetIdx vmwVmNetEntry 2
Identifies a unique network adapter in this table. May
change across sytem reboots.
vmwVmNetNum vmwVmNetEntry 3
The name of the network adapter as it appears in the
virtual machine settings.
vmwVmNetName vmwVmNetEntry 4
Identifies what the network adapter is connected to.
vmwVmNetConnType vmwVmNetEntry 5
Obsolete. Do not use.
vmwVmNetConnected vmwVmNetEntry 6
Reports true if the ethernet virtual device is connected
to the virtual machine.
vmwVmMAC vmwVmNetEntry 7
Reports the configured virtual hardware MAC address.
If VMware Tools is not running, the value is zero or
empty.
Virtual Floppy Device Variables
vmwFloppyTable vmwVirtMachines 5
A table of floppy drives for all virtual machines in
vmwVmTable.
