Table 5-8. Identification Mappings for VMWARE-RESOURCES-MIB (Continued)
Variable ID Mapping Description
vmwHbaBusNumber vmwHostBusAdapterEntry 3
The host bus number. For unsupported adapters,
returns -1.
vmwHbaStatus vmwHostBusAdapterEntry 4
The operational status of the adapter.
vmwHbaModelName vmwHostBusAdapterEntry 5
The model name of the adapter.
vmwHbaDriverName vmwHostBusAdapterEntry 6
The name of the adapter driver.
vmwHbaPci vmwHostBusAdapterEntry 7
The PCI ID of the adapter.
VMWARE-SYSTEM-MIB
The VMWARE-SYSTEM-MIB.mib file provides variables for identifying the VMware software running on a managed
system by product name, version number, and build number.
Table 5-9 lists the variables defined in VMWARE-SYSTEM-MIB.mib.
Table 5-9. Variables Defined in VMWARE-SYSTEM-MIB
Variable ID Mapping Description
vmwProdName vmwSystem 1
The product name.
vmwProdVersion vmwSystem 2
The product version number, in the format
<Major>.<Minor>.<Update>.
vmwProdBuild vmwSystem 4
The product build number.
VMWARE-TC-MIB
The VMWARE-TC-MIB.mib file provides common textual conventions used by VMware MIB files.
VMWARE-TC-MIB.mib defines the following integer values for VmwSubsystemTypes:
n
unknown(1)
n
chassis(2)
n
powerSupply(3)
n
fan(4)
n
cpu(5)
n
memory(6)
n
battery(7)
n
temperatureSensor(8)
n
raidController(9)
n
voltage(10)
VMWARE-TC-MIB.mib defines the following integer values for VmwSubsystemStatus:
n
unknown(1)
n
normal(2)
n
marginal(3)
n
critical(4)
n
failed(5)
