VMWARE-PRODUCTS-MIB
The VMWARE-PRODUCTS-MIB.mib file defines OIDs to uniquely identify each SNMP agent on each VMware
platform.
Table 5-7 lists identification mappings defined in VMWARE-PRODUCTS-MIB.mib.
Table 5-7. Identification Mappings for VMWARE-PRODUCTS-MIB.mib
Label Identification Mapping
oidESX vmwOID 1
vmwESX vmwProductSpecific 1
vmwDVS vmwProductSpecific 2
vmwVC vmwProductSpecific 3
vmwServer vmwProductSpecific 4
VMWARE-RESOURCES-MIB
The VMWARE-RESOURCES-MIB.mib file defines variables used to report information on resource usage.
Table 5-8 lists the identification mappings defined in VMWARE-RESOURCES-MIB.mib.
Table 5-8. Identification Mappings for VMWARE-RESOURCES-MIB
Variable ID Mapping Description
CPU Subtree
vmwCPU vmwResources 1
Defines the root OID for the subtree of variables
used to report CPU information.
vmwNumCPUs vmwCPU 1
The number of physical CPUs present on the
system.
Memory Subtree
vmwMemory vmwResources 2
Defines the root OID for the subtree of variables
used to report memory information.
vmwMemSize vmwMemory 1
Amount of physical memory present on the host (in
KB).
vmwMemCOS vmwMemory 2
Amount of physical memory allocated to the service
console (in KB). This variable does not apply to ESXi
hosts, which do not have a service console.
vmwMemAvail vmwMemory 3
The amount of memory available to run virtual
machines and to allocate to the hypervisor. It is
computed by subtracting vmwMemCOS from
vmwMemSize.
Storage Subtree
vmwStorage vmwResources 5
Defines the root OID for the subtree of variables
used to report memory information.
vmwHostBusAdapterNumber vmwStorage 1
The number of entries in the
vmwHostBusAdapterTable.
vmwHostBusAdapterTable vmwStorage 2
A table of Host Bus Adapters found in this host.
vmwHostBusAdapterEntry vmwHostBusAdapterTable 1
An entry in the Host Bus Adapter table holding
details for a particular adapter.
vmwHostBusAdapterIndex vmwHostBusAdapterEntry 1
An arbitrary index assigned to this adapter.
vmwHbaDeviceName vmwHostBusAdapterEntry 2
The system device name for this adapter.
