Table 5-5. Variables Defined in VMWARE-OBSOLETE-MIB (Continued)
Variable ID Mapping Description
vmwNetHCPktsTx vmwNetEntry 10
The number of packets transmitted on
this network adapter since the network
module was loaded. This counter is the
64-bit version of vmwNetPktsTx.
vmwNetHCKbTx vmwNetEntry 11
The number of kilobytes sent from this
network adapter since the network
module was loaded. This counter is the
64-bit version of vmwNetKbTx.
vmwNetHCPktsRx vmwNetEntry 12
The number of packets received on this
network adapter since the network
module was loaded. This counter is the
64-bit version of vmwNetPktsRx.
vmwNetHCKbRx vmwNetEntry 13
The number of kilobytes received on
this network adapter since the network
module was loaded. This counter is the
64-bit versin of vmwNetKbRx.
Obsolete variables originally defined in VMWARE-TRAPS-MIB
vmID vmwTraps 101
The ID of the affected virtual machine
generating the trap. If there is no virtual
machine ID (for example, if the virtual
machine has been powered off), the
vmID is -1.
vmConfigFile vmwTraps 102
The configuration file of the virtual
machine generating the trap.
vpxdTrapType vmwTraps 301
The trap type of the vCenter Server trap.
vpxdHostName vmwTraps 302
The name of the affected host.
vpxdVMName vmwTraps 303
The name of the affected virtual
machine.
vpxdOldStatus vmwTraps 304
The prior status.
vpxdNewStatus vmwTraps 305
The new status.
vpxdObjValue vmwTraps 306
The object value.
Table 5-6 lists the traps defined in VMWARE-OBSOLETE-MIB.mib. These traps were originally defined in VMWARE-
TRAPS-MIB.mib.
Table 5-6. Traps Defined in VMWARE-OBSOLETE-MIB
Trap Description
ESX/ESXi Traps
vmPoweredOn
This trap is sent when a virtual machine is powered on from a suspended or powered off
state.
vmPoweredOff
This trap is sent when a virtual machine is powered off.
vmHBLost
This trap is sent when a virtual machine detects a loss in guest heartbeat. VMware Tools
must be installed in the guest operating system in order for this value to be valid.
vmHBDetected
This trap is sent when a virtual machine detects or regains the guest heartbeat. VMware
Tools must be installed in the guest operating system in order for this value to be valid.
vmSuspended
This trap is sent when a virtual machine is suspended.
vCenter Server Traps
vpxdTrap
This trap is sent when an entity status has changed.
Chapter 5 Configuring Hosts and vCenter Server
