Table 5-4. Variable Definitions in VMWARE-ENV-MIB (Continued)
Variable ID Mapping Description
vmwSubsystemType vmwEnvEntry 2
The type of hardware component that is
reporting its environmental state.
vmwHardwareStatus vmwEnvEntry 3
The last reported status of the
component.
vmwEventDescription vmwEnvEntry 4
A description of the last reported event
for this hardware component.
vmwHardwareTime vmwEnvEntry 5
The value of sysUptime when
vmwHardwareStatus was reported.
VMWARE-OBSOLETE-MIB
The VMWARE-OBSOLETE-MIB.mib file contains all previously published managed objects that have been made
obsolete. This file is provided to maintain compatibility with older versions of ESX/ESXi.
The variables defined in this file were originally defined in previous versions of the VMWARE-RESOURCES-
MIB.mib and VMWARE-TRAPS-MIB.mib files. Table 5-5 lists the variables defined in VMWARE-OBSOLETE-MIB.mib.
Table 5-5. Variables Defined in VMWARE-OBSOLETE-MIB
Variable ID Mapping Description
Obsolete variables originally from VMWARE-RESOURCES-MIB
vmwResources vmware 3
vmwCPU vmwResources 1
Defines the root OID for the subtree of
variables used to report CPU
information.
vmwCpuTable vmwCPU 2
A table of CPU usage by each virtual
machine.
vmwCpuEntry vmwCpuTable 1
An entry in cpuTable that records CPU
usage for a single virtual machine.
vmwCpuVMID vmwCpuEntry 1
The identification number allocated to
the virtual machine by the VMkernel.
vmwCpuShares vmwCpuEntry 2
The share of the CPU allocated to the
virtual machine by the VMkernel.
vmwCpuUtil vmwCpuEntry 3
Amount of time the virtual machine has
been running on the CPU (in seconds).
vmwMemTable vmwMemory 4
A table of memory usage by each virtual
machine.
vmwMemEntry vmwMemTable 1
An entry in memTable that records
memory usage by a single virtual
machine.
vmwMemVMID vmwMemEntry 1
The identification number allocated to
the virtual machine by the VMkernel.
vmwMemShares vmwMemEntry 2
The shares of memory allocated to the
virtual machine by the VMkernel.
vmwMemConfigured vmwMemEntry 3
The amount of memory the virtual
machine was configured with (in KB).
vmwMemUtil vmwMemEntry 4
The amount of memory currently used
by the virtual machine (in KB).
vmwHBATable vmwResources 3
A table used for reporting disk adapter
and target information.
