Procedure
1 Select a host, cluster, resource pool, or virtual machine in the inventory panel.
2 Click the Performance tab.
3 Click Advanced.
4 To view a different chart, select an option from the Switch to list.
The default charts are configured to show the following information.
Option Description
CPU
Shows the CPU usage in MHz. Available for clusters, resource pools, hosts,
and virtual machines.
Memory
Shows the amount of memory granted. Available for clusters, resource pools,
hosts, and virtual machines.
Disk
Shows the aggregated storage performance statistics. Available for hosts and
virtual machines.
Network
Shows the aggregated network performance statistics. Available for hosts
and virtual machines.
System
Shows statistics for overall system availability, including CPU usage by the
service console and other aapplications. Available for hosts and virtual
machines.
Cluster Services
Shows aggregate CPU, aggregate memory, and failover statistics for DRS
and HA clusters and hosts that are part of DRS clusters.
The amount of historical data displayed in a chart depends on the collection interval and collection level
set for vCenter Server.
Save Chart Data to a File
You can save data from the Advanced performance charts to a file in various graphics formats or in Microsoft
Excel format.
Procedure
1 In the Performance tab, click Advanced.
2 Click Save.
3 In the Save Performance Chart dialog box, navigate to the location to save the file.
4 Enter a name for the file.
5 Select a file type.
6 Click Save.
The file is saved to the location and format you specified.
Export Performance Data to a Spreadsheet
You can export performance data from the Advanced charts to a Microsoft Office Excel file. You use the vSphere
Client to export data.
Prerequisites
Before you view or export performance data, verify that the time is set correctly on the ESX/ESXi host, the
vCenter Server system, and the client machine. Each host and client machine can be in different time zones,
but the times must be correct for their respective time zones.
