4 Select the device type to use for this virtual device.
Option Description
Client Device
Select this option to connect the floppy device to a physical floppy device on
the system running the vSphere Client.
To connect the device, you must click the Connect Floppy button in the
toolbar when you power on the virtual machine.
Host Device
a Select this option to connect the floppy device to a physical floppy device
on the host.
b Select the specific device from the drop-down list.
Use existing floppy image in
datastore
a Select this option to connect the virtual device to an existing floppy image
on a datastore accessible to the host.
b Click Browse and select the floppy image.
Create new floppy image in datastore
a Select this option to create a new floppy image on a datastore accessible
to the host.
b Click Browse and browse to the location for the floppy image.
c Enter a name for the floppy image and click OK.
5 Click OK to save your changes and close the dialog box.
Change the SCSI Device Configuration
You can change the physical device and the virtual device node of the SCSI device connection.
Procedure
1 In the Virtual Machine Properties Editor, click the Hardware tab.
2 Select the SCSI device in the Hardware list.
3 Under Connection, select the physical device you want to use.
Under Virtual device node, select the virtual device node where you want this device to appear in the
virtual machine.
4 Click OK to save your changes and close the dialog box.
Change the Virtual Disk Configuration
You can change the virtual device node, the size of the disk, and the persistence mode for virtual disk
configuration for a virtual machine.
NOTE The Manage Paths feature for RDM disks is not available for virtual machines on legacy hosts running
versions of ESX Server prior to release 3.0.
Procedure
1 In the Virtual Machine Properties Editor, click the Hardware tab.
2 Click the appropriate Hard Disk in the Hardware list.
3 Use the drop-down menu to change the virtual device node.
4 To change the size of the disk, enter a new value in the Provisioned Size text box.
5 For independent mode, which is unaffected by snapshots, select the check box. Then select Persistent or
Nonpersistent mode to determine the persistence of changes.
6 Click OK to save your changes and close the dialog box.
