Specifications
8 9
Installation Getting Started
CAUTION!
• Before installing this subwoofer product, inspect all hardware,
brackets, surfaces, cabinets and associated equipment
for damage. If a fault is discovered, it should be corrected
immediately.
• Never connect multiple amplier outputs to the parallel
speakon or 1/4” jack speaker wire connectors at the
same time. This may cause a short and may damage your
equipment or cause a re.
• This subwoofer can easily reproduce sound pressure levels
(SPL) loud enough to cause permanent ear damage that
could result in hearing loss. Take great precaution to protect
yourself from prolonged exposure to high output sound
pressure levels.
Step 1
Carefully run the speaker wires or cable from the amplier
up to the location of the subwoofer.
Subwoofer Installation
Subwoofer & Loudspeaker Placement
The Shaker DJ Series Subwoofers were designed to sit on
a solid at surface.
• Follow the user guide installation procedures to install your
Shaker DJ Subwoofer into your own sound system.
• Place the subwoofer cabinet on a solid level surface where
it cannot be toppled or tilted.
• If a Shaker DJ loudspeaker is to be pole mounted, ensure
the tripod is on a at solid surface and on a location where
it cannot be toppled or tilted by the audience or personnel.
• When using a Shaker DJ loudspeaker, place the speaker at
or above head level. This is to prevent the high frequencies
from being blocked and getting mufed by obstacles
directly in front of the tweeters.
• Avoid placing full-range loudspeakers in a corner or right
next to a wall to avoid degrading the overall sound quality.
• If loudspeakers are to be placed in locations where large
amounts of reverberations or echoes are produced, such
as gymnasiums and auditoriums, laying carpet or rugs will
help dampen the reections and improve the overall sound
quality of the system.
