USER’S GUIDE 17
CUSTOMER PREMISES EQUIPMENT AND WIRING
CUSTOMER PREMISES EQUIPMENT AND WIRINGCUSTOMER PREMISES EQUIPMENT AND WIRING
CUSTOMER PREMISES EQUIPMENT AND WIRING
The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a
telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of
RENs should not exceed five. To be certain of the number of devices that may be connected to a line, as determined by
the total RENs, contact the local telephone company. The REN of an alarm system is part of the product identifier that
has the format US:VSOAL00BAMBER SELECT / AMBER SELECT
X
.
RJ-31X
JACK
RJ-31X CORD
TO LINE JACK
1 2
3
4
5
6
7
8
TEL
LINES
For locations with
DSL service
DSL
FILTER
Note: For whole house line seizure
with DSL service present on the phone
line, you must install a filter. It is
suggested to use the DSL alarm filter
model Z-A431PJ31X manufactured by
Excelsus Technologies, or equivalent.
This filter simply plugs into the RJ-31X
jack and allows alarm reporting without
breaking the internet connection.
Customer Information
Customer InformationCustomer Information
Customer Information
The required customer information is provided in the User Guide (manual).
1.
This equipment, wireless emergency response system, model “AMBER SELECT / AMBER SELECT
X
”,
complies with Part 68 of the FCC Rules and the requirements adopted by the ACTA. On the bottom panel of
this equipment is a label, that contains among other information, a product identifier in the format
US:VSOAL00BAMBERNA. If requested, this number must be provided to the telephone company.
2.
This equipment is designed to be connected to the telephone network using RJ11 connector which complies
with Part 68 rules and requirements adopted by ACTA and properly installed RJ31X connector. See Installation
Instructions for details.
3.
If the “AMBER SELECT / AMBER SELECT
X
” causes harm to the telephone network, the telephone company
will notify you in advance that temporary discontinuance of service may be required. If advance notice is not
practical, you will be notified as soon as possible. Also, you will be advised of your right to file a compliant with
the FCC if it is necessary.
4.
The telephone company may make changes in its facilities, equipment, operations or procedures that could
affect the operation of the equipment. If this happens the telephone company will provide advance notice in
order for you to make necessary modifications to maintain uninterrupted service.
5.
If the equipment is causing harm to the telephone network, the telephone company may request to disconnect
the equipment until the problem is resolved.
6.
The “AMBER SELECT / AMBER SELECT
X
” installation is described in the User Guide. Connection to telephone
company provided coin service is prohibited. Connection to party lines service is subject to state tariffs.
7.
Wireless emergency response system must be able to seize the telephone line and place a call in an
emergency situation. It must be able to do this even if other equipment (telephone, answering system,
computer modem, etc.) already has the telephone line in use. To do so, “AMBER SELECT / AMBER
SELECT
X
” must be connected to a properly installed RJ31X jack that is electrically in series with and ahead of
all other equipment attached to the same telephone line. Proper installation is depicted in the figure below. If
you have any questions concerning these instructions, you should consult your telephone company or a
qualified installer about installing the RJ31X jack and “AMBER SELECT / AMBER SELECT
X
” for you.
