User`s guide

10 D-301438 AMBER SELECT / AMBER SELECT
X
USER’S GUIDE
In the Event that No Activity
is detected (Motion Detector /
Transmitter - Optional)
The motion detector and door contact transmitter are
used to monitor the user's activity. If no activity is
detected by the enrolled transmitter(s) during a pre-
defined time, the AMBER SELECT / AMBER SELECT
X
will report an inactivity condition to the Monitoring
Center, which will initiate a two-way voice
communication. Inactivity time periods are defined
remotely by the central station.
Non-Emergency Services (CALL)
The Monitoring Center provides non-emergency
(concierge-type) services.
When you press the CALL button ( ), the unit displays
(AMBER SELECT only) CALL WAS PRESSED. If NON -
EMERGENCY services are available to you, the AMBER
SELECT / AMBER SELECT
X
will contact the Monitoring
Center and open a two-way voice communication.
You can use the CALL button ( ) to speak to a Monitoring
Center representative about your system. Because the call is
non-emergency call, there might be a delay before the
Monitoring Center representative responds.
As long as the display (AMBER SELECT only) shows
CALL WAS PRESSED, you do not need to press the
button again. A representative will begin speaking to
you shortly.
Remote two-way voice
communication access
You can access the AMBER SELECT / AMBER
SELECT
X
system from a remote telephone, for 2-way
voice communication, as follows:
1. Dial the AMBER SELECT / AMBER SELECT
X
tel. No.
2. Wait for 2-4 rings then hang up.
3. Wait 12-30 sec.
4. Redial AMBER SELECT / AMBER SELECT
X
tel. No.
"Please enter user code" is heard and "Remote
access" is displayed
5. Enter the user code. Entering of the user code must
be completed within 10 seconds.
If a valid user code was entered, the message, happy
tune will be heard and the message "REMOTE 2WAY"
"VOICE ACCESS" will be displayed.
Remote control by telephone
Both the central station and any person to whom the
AMBER SELECT / AMBER SELECT
X
unit is dialing can
perform a number of actions using the AMBER
SELECT / AMBER SELECT
X
unit, as follows:
Pressed
button
Performs
2 Acknowledge private report
9 99 sequence ends of voice session after
emergency report
1 Half duplex: speaker ON, microphone OFF
3 Half duplex: microphone ON, speaker OFF
Pressed
button
Performs
6 Automatic full duplex
4 Increase speaker volume
7 Decrease speaker volume
5 Trouble announcement
8 Trouble stop
*, # **# sequence toggles USER TEST
MODE ON/OFF
0 Not in use
*1# AWAY ARMING
*3# HOME ARMING
Using the Amber select/
AMBER SELECT
X
Intrusion
Alarm System (Optional)
You can perform the following functions in the AMBER
SELECT / AMBER SELECT
X
alarm system:
• Arm the system in Away mode.
• Disarm the system.
• Disarm the system after alarm activation.
• View the cause of the alarm activation.
You can arm / disarm the system using either the Amber
controller or a Power Code transmitter (MCT-201WP).
To arm the system by the AMBER SELECT / AMBER
SELECT
X
unit, press and hold the CHECK button for 3
seconds. The unit announces ARMING AWAY -
PLEASE EXIT NOW and displays (AMBER SELECT
only) EXIT on the screen. At the end of exit delay the unit
announces AWAY, REMINDERS OFF and displays
(AMBER SELECT only) AWAY on the screen, to inform
you that the system is in AWAY state.
When a delay zone is entered, the unit announces
PLEASE DISARM and displays (AMBER SELECT only)
ENTRY on the screen. To inform you that the system is
in disarmed state (at the end of an entry delay or after
pressing the button on the MCT-201WP) the unit
announces HOME, REMINDERS ON and displays
(AMBER SELECT only) HOME on the screen.
If any Zone in your home is opened (except the Delay
Zone) during the system arming, a beep protest will
sound during Exit delay time out (if enabled by the
central station), and stopped if this Zone is closed.
If the Zone is still opened after the system is in Arm state,
this zone will be automatically bypassed (except in the
case of an EXIT/ENTRY zone) until system rearming.
Note: Reminders are active during Home mode and
are disabled during Away and Exit/Entry delay mode.
Entry/exit delay setting must only be performed by
installers or service professionals.
In the alarm state, the unit announces ALARM then the
Amber will start its communication sequence to either
private or central station telephone numbers according to
pre-defined parameters.
If the Zone is still opened after the system is in Arm
state, this zone is automatically bypassed until
disarming and rearming of the system.
