SMA
Outline Dimensions
Vishay Semiconductors
DIMENSIONS in inches (millimeters)
DO-214AC (SMA)
Mounting Pad Layout
0.008 (0.203)
0.194 (4.93)
0.208 (5.28)
0.157 (3.99)
0.177 (4.50)
0.100 (2.54)
0.110 (2.79)
0.078 (1.98)
0.090 (2.29)
0.006 (0.152)
0.012 (0.305)
0.049 (1.25)
0.065 (1.65)
Cathode band
0 (0)
0.030 (0.76)
0.060 (1.52)
0.074 (1.88)
MAX.
0.208 (5.28)
REF.
0.066 (1.68)
MIN.
0.060 (1.52)
MIN.
