Datasheet

SS2P2L, SS2P3L
www.vishay.com
Vishay General Semiconductor
Revision: 13-Apr-15
2
Document Number: 88916
For technical questions within your region: [e-mail]
, [e-mail], [e-mail]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Notes
(1)
Pulse test: 300 μs pulse width, 1 % duty cycle
(2)
Pulse test: Pulse width  40 ms
Note
(1)
Thermal resistance from junction to ambient and junction to lead mounted on PCB with 5.0 mm x 5.0 mm copper pad areas. R
JL
is measured
at the terminal of cathode band. R
JC
is measured at the top center of the body
Note
(1)
Automotive grade
RATINGS AND CHARACTERISTICS CURVES (T
A
= 25 C unless otherwise noted)
Fig. 1 - Forward Current Derating Curve Fig. 2 - Maximum Non-Repetitive Peak Forward Surge Current
ELECTRICAL CHARACTERISTICS (T
A
= 25 °C unless otherwise noted)
PARAMETER TEST CONDITIONS SYMBOL TYP. MAX. UNIT
Maximum instantaneous forward voltage
I
F
= 2 A T
J
= 25 °C
V
F
(1)
0.45 0.50
V
I
F
= 2 A T
J
= 125 °C 0.38 0.45
Maximum reverse current at rated V
R
T
J
= 25 °C
I
R
(2)
- 200 μA
T
J
= 125 °C 9.0 20 mA
Typical junction capacitance 4.0 V, 1 MHz C
J
130 pF
THERMAL CHARACTERISTICS (T
A
= 25 °C unless otherwise noted)
PARAMETER SYMBOL SS2P2L SS2P3L UNIT
Typical thermal resistance
R
JA
(1)
115
°C/W R
JL
(1)
15
R
JC
(1)
20
ORDERING INFORMATION (Example)
PREFERRED P/N UNIT WEIGHT (g) PREFERRED PACKAGE CODE BASE QUANTITY DELIVERY MODE
SS2P3L-M3/84A 0.024 84A 3000 7" diameter plastic tape and reel
SS2P3L-M3/85A 0.024 85A 10 000 13" diameter plastic tape and reel
SS2P3LHM3/84A
(1)
0.024 84A 3000 7" diameter plastic tape and reel
SS2P3LHM3/85A
(1)
0.024 85A 10 000 13" diameter plastic tape and reel
0
2.4
80 90 100 110 120 130 140 150
1.6
2.0
0.4
0.8
1.2
T
L
Measured
at the Cathode Band Terminal
Average Forward Rectied Current (A)
Lead Temperature (°C)
Peak Forward Surge Current (A)
Number of Cycles at 50 Hz
1
10
100
10
20
30
0
40
50
