Vishay Siliconix
Si5855CDC
TYPICAL CHARACTERISTICS 25 °C, unless otherwise noted
Threshold Voltage
0.2
0.3
0.4
0.5
0.6
0.7
- 50 - 25 0 25 50 75 100 125 150
I
D
= 250 µA
(V)V
GS(th)
T
J
- Temperature (°C)
Single Pulse Power
0
1
2
3
4
5
0.001 0.01 0.1 1 10 100
Time (s)
Power (W)
Safe Operating Area, Junction-to-Ambient
100
1
0.1 1 10 100
0.01
10
0.1
T
A
= 25 °C
Single Pulse
Limited byR
DS(on)
*
BVDSS Limited
1ms
100 µs
10 ms
100 ms
1s,10s
DC
V
DS
- Drain-to-Source Voltage (V)
* V
GS
> minimum V
GS
at which R
DS(on)
is specified
- Drain Current (A)
I
D
