Datasheet
MUR2020CT, MURB2020CT, MURB2020CT-1
Bulletin PD-20729 rev. B 01/01
2
V
BR
,
V
r
Breakdown Voltage, 200 - - V I
R
= 100µA
Blocking Voltage
V
F
Forward Voltage - - 0.85 V I
F
= 8A, T
J
= 125°C
- - 1.15 V I
F
= 16A, T
J
= 25°C
- - 1.05 V I
F
= 16A, T
J
= 125°C
I
R
Reverse Leakage Current - - 15 µA V
R
= V
R
Rated
- - 250 µA T
J
= 150°C, V
R
= V
R
Rated
C
T
Junction Capacitance - 55 - pF V
R
= 200V
L
S
Series Inductance - 8.0 - nH .
Electrical Characteristics @ T
J
= 25°C (unless otherwise specified)
Parameters Min Typ Max Units Test Conditions
Measured lead to lead 5mm from package body
t
rr
Reverse Recovery Time --35 ns I
F
= 1.0A, di
F
/dt = 50A/µs, V
R
= 30V
--25 I
F
= 0.5A, I
R
= 1.0A, I
REC
= 0.25A
-21- T
J
= 25°C
35 T
J
= 125°C
I
RRM
Peak Recovery Current - 1.9 - A T
J
= 25°C
- 4.8 - T
J
= 125°C
Q
rr
Reverse Recovery Charge - 25 - nC T
J
= 25°C
-78- T
J
= 125°C
Dynamic Recovery Characteristics @ T
J
= 25°C (unless otherwise specified)
I
F
= 10A
V
R
= 160V
di
F
/dt = 200A/µs
Parameters Min Typ Max Units Test Conditions
Parameters Min Typ Max Units
T
J
Max. Junction Temperature Range - - - 65 to 175 °C
T
Stg
Max. Storage Temperature Range - - - 65 to 175
R
thJC
Thermal Resistance, Junction to Case Per Leg - - 2.5 °C/W
R
thJA
Thermal Resistance, Junction to Ambient Per Leg - - 50
R
thCS
Thermal Resistance, Case to Heatsink - 0.5 -
Wt Weight - 2.0 - g
- 0.07 - (oz)
Mounting Torque 6.0 - 12 Kg-cm
5.0 - 10 lbf.in
Thermal - Mechanical Characteristics
! Typical Socket Mount
"#Mounting Surface, Flat, Smooth and Greased
"
!
