MSS2P2, MSS2P3
www.vishay.com
Vishay General Semiconductor
Revision: 20-Jan-14
2
Document Number: 89054
For technical questions within your region: [e-mail]
, [e-mail], [e-mail]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Note
(1)
Thermal resistance from junction to ambient and junction to lead mounted on PCB with 6.0 mm x 6.0 mm copper pad areas R
JL
is measured 
at the terminal of cathode band. R
JC
is measured at the top center of the body
Note
(1)
Automotive grade
RATINGS AND CHARACTERISTICS CURVES (T
A
= 25 °C unless otherwise noted)
Fig. 1 - Maximum Forward Current Derating Curve
Fig. 2 - Forward Power Loss Characteristics
Fig. 3 - Typical Instantaneous Forward Characteristics
Fig. 4 - Typical Reverse Characteristics
THERMAL CHARACTERISTICS (T
A
= 25 °C unless otherwise noted)
PARAMETER SYMBOL MSS2P2 MSS2P3 UNIT
Typical thermal resistance
R
JA
(1)
105
°C/WR
JL
(1)
15
R
JC
(1)
20
ORDERING INFORMATION (Example)
PREFERRED P/N UNIT WEIGHT (g) PREFERRED PACKAGE CODE BASE QUANTITY DELIVERY MODE
MSS2P3-M3/89A 0.006 89A 4500 7" diameter plastic tape and reel
MSS2P3HM3/89A
(1)
0.006 89A 4500 7" diameter plastic tape and reel
Average Forward Rectied Current (A)
Lead Temperature (°C)
80
0
0.4
0.8
1.2
1.6
2.0
2.4
90 100 110 120 140 150
T
L
Measured
at the Cathode Band Terminal
130
1.4
1.2
0.8
0.4
0.2
0
0 0.4 0.8 1.2 1.6 2.0 2.4
Average Forward Current (A)
Average Power Loss (W)
D = 0.1
D = 0.2
D = 0.3
D = 0.5
D = 0.8
D = 1.0
1.0
0.6
D = t
p
/T t
p
T
10
1
0.1
0.01
0.10 0.2 0.3 0.4 0.5 0.6 0.7 0.8
Instantaneous Forward Voltage (V)
Instantaneous Forward Current (A)
T
J
= 150 °C
T
J
= 125 °C
T
J
= 25 °C
100
10
10 20 30 40 50 60 70 80 90 100
1
0.1
0.01
0.001
Percent of Rated Peak Reverse Voltage (%)
Instantaneous Reverse Current (mA)
T
J
= 150 °C
T
J
= 125 °C
T
J
= 25 °C
